Modular "Hi-Bel" Rectifiers
Advanced diffusion and manufacturing techniques allow us to produce a wide range of rectifier products. Tight control of these designs and processes allow for custom versions of any product within this line, and delivery on short lead times.
Features:
- High voltage, high current capability
- Large plated brass base-plate heat sink on cathode side
- Molded encapsulation, ANSI/UL94 V-0 rated material
- RoHS compliant to Directive 2011/65/EC
- Can be easily cascaded for higher voltage system applications
Products
Data Sheets
Products
HD Series
| Part # | Repetitive Pk. Reverse Voltage (V) | Forward Voltage Drop (V) | Avg. Forward Current (A) | Surge Current (A) | Rev. Recovery Time (nS) |
| Fast Recovery 1&3A | |||||
| HDD2.5 | 2500 | 4 | 2.3 | 100 | 250 |
| HDC5 | 5000 | 7 | 1.2 | 100 | 250 |
| HDD5 | 5000 | 7 | 1.5 | 100 | 250 |
| HDC7.5 | 7500 | 11 | 0.9 | 100 | 250 |
| HDD7.5 | 7500 | 11 | 1 | 100 | 250 |
| HDC10 | 10000 | 13 | 0.8 | 50 | 150 |
| HDC15 | 15000 | 22 | 0.6 | 50 | 150 |
| Fast Recovery 6A | |||||
| HDEF2.5 | 2500 | 3.6 | 3 | 200 | 350 |
| HDEF5 | 5000 | 6 | 3 | 200 | 350 |
| Stand. Recovery 1&3A | |||||
| HDB2.5 | 2500 | 2.2 | 3 | 150 | – |
| HDA5 | 5000 | 4.5 | 1.7 | 150 | – |
| HDB5 | 5000 | 4.4 | 2 | 150 | – |
| HDA7.5 | 7500 | 6.6 | 1.3 | 150 | – |
| HDB7.5 | 7500 | 6.6 | 1.4 | 150 | – |
| HDA10 | 10000 | 9 | 1 | 150 | – |
| HDB10 | 10000 | 9 | 1.2 | 150 | – |
| HDA15 | 15000 | 12 | 0.7 | 50 | – |
| HDA20 | 20000 | 17 | 0.6 | 50 | – |
| Standard Recovery 6A | |||||
| HDE2.5 | 2500 | 3 | 4 | 400 | – |
| HDE5 | 5000 | 5 | 4 | 400 | – |
| Ultra Fast Recovery | |||||
| HDAUF5 | 5000 | 5.5 | 0.8 | 35 | 75 |
| HDBUF5.0 | 5000 | 7 | 2.25 | 150 | 75 |
| HDAUF7.5 | 7500 | 8.8 | 0.8 | 35 | 75 |
| HDBUF7.5 | 7500 | 11.2 | 2.25 | 150 | 75 |
| HDAUF10 | 10000 | 11 | 0.8 | 35 | 75 |
| HDAUF15 | 15000 | 17 | 0.8 | 35 | 75 |
| Ultra Fast Recovery | |||||
| HDT1 | 1000 | 2 | 2.5 | 250 | 50 |
| HDU1.5 | 1500 | 8 | 1 | 50 | 35 |
| HDV1.5 | 1500 | 8 | 1.4 | 125 | 35 |
| HDU2 | 2000 | 10 | 0.9 | 50 | 35 |
| HDV2 | 2000 | 10 | 1.3 | 125 | 35 |
| HDU3 | 3000 | 15 | 0.7 | 50 | 35 |
| HDT1.5 | 15000 | 3 | 2 | 250 | 50 |
| Ultra Super Fast Recov. | |||||
| HDAUSF5 | 5000 | 7 | 0.65 | 10 | 35 |
| HDBUSF5 | 5000 | 10 | 1.75 | 60 | 40 |
| HDAUSF7.5 | 7500 | 11.2 | 0.65 | 10 | 35 |
| HDAUSF10 | 10000 | 14 | 0.65 | 10 | 35 |
HGE Series
| Part # | Repetitive Pk. Reverse Voltage (V) | Forward Voltage Drop (V) | Avg. Forward Current (A) | Surge Current (A) | Rev. Recovery Time (nS) |
| HGE2.5 | 2500 | 3.3 | 8 | 200 | – |
| HGE5 | 5000 | 5.5 | 8 | 200 | – |
HGF Series
| Part # | Repetitive Pk. Reverse Voltage (V) | Forward Voltage Drop (V) | Avg. Forward Current (A) | Surge Current (A) | Rev. Recovery Time (nS) |
| HGF2.5 | 2500 | 5.2 | 8 | 150 | 150 |
| HGF5 | 5000 | 9 | 8 | 150 | 150 |
HGU Series
| Part # | Repetitive Pk. Reverse Voltage (V) | Forward Voltage Drop (V) | Avg. Forward Current (A) | Surge Current (A) | Rev. Recovery Time (nS) |
| HGU2 | 2000 | 6 | 10 | 250 | 50 |
